Description
PTFE rod can be manufacture from extrusion tube and moulded. Extruded ptfe rods OD from 6mm to 260mm. Molded ptfe rods from 30mm to 400mm.Filled ptfe rod ( Filled Fiber glass, Filled graphite, Filled Bronze, Filled Carbon ), Size OD from30mm to 400mm.
1, PTFE Rods Specification:
| Item description | Dia.(mm) | Length(mm) | Color |
| Extruded PTFE rod | 6-260mm | 1000-2000 | white |
| Molded PTFE rod | 30-400 | 100-300 | white |
| Filled Glass PTFE rod | 30-400 | 100-300 | gray |
| Filled graphite PTFE rod | 10-400 | 100-300 | black |
| Filled MoS2 PTFE rod | 30-400 | 100-300 | gray |
| Filled Carbon PTFE rod | 30-500 | 100-300 | black |
| Filled POB PTFE rod | 80-200 | 100-300 | Yellow |
| Filled Peek PTFE rod | 80-200 | 100-300 | white |
2, PTFE Rod Parameter
| Item name | Unit | Result |
| Density | g/cm³ | 2.10-2.30 |
| Tensile strength | MPa | ≧ 15 |
| Ultimate elongation | % | ≧150 |
| Operating temperature | ℃ | -180～+260 |
| Compression Strength | Kgf/cm³ | 40-50 |
3, PTFE Rod Features and Benefits
- Exceptional Chemical Resistance:Resistant to almost all industrial chemicals and solvents.
- High-Temperature Stability:Performs consistently across a wide temperature range.
- Low Friction Coefficient:Offers excellent non-stick and low-friction properties.
- Electrical Insulation:Ideal for electronic applications due to its high dielectric strength.
- Non-reactive and Biocompatible:Safe for use in medical and food-related applications.
4, PTFE Rod application
- Bearings and bushings
- Gears
- Slide plates
- Gaskets
- Valve stem seals, valve seats
- Chute liners
- Pump parts
- Cable insulation
- Connector assemblies
- Electrical sleeves
- Semiconductor equipment
- Scientific, medical equipment
- Chemical resistant tubing
- Shims
- Oven plates
- Non-stick and release coating
5, Profile PTFE rods
We welcome inquires about extruded profiles no matter how complex, and tooling costs will usually be charged to the customer.
Pls contact us at jessime.sunriseptfe@gmail.com or info@sunriseptfe.com, or send message to whatsapp at +8613951184240
